Automated Closed Captioning - ACE 2000 / 2100 / 2200Model No: ACE-2000 / 2100 / 2200
Click above image to open expanded view
Superior Automated Closed Captioning
Captioning is not only a desired service, but is a requirement for ADA Compliance. Link Electronics ACE line consists of three units that provide a range of options to fit nearly any automatic captioning need. The ACE-2000, ACE-2100, and ACE-2200 are Automated Captioning Engines that receive audio containing speech and, using a cutting-edge computational linguistics program, convert speech to text and sends that text out with captioning data to be encoded by a closed captioning encoder. The ACE units are able to achieve an average of 95 percent accuracy in English and Spanish with an average delay of 3-5 seconds.
The ACE-2000 can accept audio in many different ways. It can de-embed the first two channels of audio from an SDI input or an HDMI input. Balanced AES or balanced analog audio is another method that the ACE-2000 accepts audio. The unit also has the ability to receive streaming audio using http, tcp, udp, mmsh, and most types of rstp and rtmp. It also supports the most commonly used codex. The captioning data and text can be sent out by either RS 232 (Serial) or TCP/IP.
The ACE-2100 is a network resource that can be used by any system on your existing network without requiring additional network or system resources. The textual transcription files can be reviewed, edited, or inserted off-line for post-production captioning. Some of the file types include text files, caption files, subtitle files, or time coded text files.
The ACE-2200 is a combination of the ACE 2000 and ACE 2100 in a single unit and is capable of live captioning from one of multiple live sources, as well as being able to caption in post production, however, both programs cannot run simultaneously. This unit provides a one stop captioning solution for both live captioning and post production captioning.
All ACE units include a web based Graphical User Interface (GUI) that will allow remote controlling of this device. The GUI contains an event scheduler that allows the use of different audio inputs and caption outputs at different times. The units comes preset with standard audio and caption data outputs for Link encoders making the setup for the device simple. A keyboard, mouse, and monitor will be required to change the settings from the standard setup. These units are compatible with most closed captioning encoders or devices.
The system does not need to be “taught” and is updated regularly with an internet connection. Words can be manually entered into the system's dictionary to increase the ACE’s accuracy. To further ADA compliance, the ACE can identify individual speakers to provide a speaker ID with the automatic closed captions.
We Tailor Solutions For You
All ACE units are available in two convenient bundles that include either Link Electronics SCE-492 Superior Caption Encoder, or Link Electronics AIP-494 Audio over IP Caption Encoder for a complete automated captioning and encoding solution. We understand that purchasing new equipment can be expensive, which is why we offer multiple ways to pay for the unit. We’ve partnered with Taycor Financial to make your purchasing decision easier by providing leasing and financing options to help you acquire the equipment you need with a low monthly payment. Link Electronics is also offering a rental program for the ACE units giving you the flexibility you need at a low cost.
Our Customer Service Is Unbeatable
We provide free 24/7 technical support and warranty for the first year for the ACE-2000. We strive to put our customers first which is why we drop everything to help you. Whether you are calling our office during normal business hours or calling the after hours number, we go the extra mile to make sure our customers walk away with solutions, not frustrations.
- RS 232 Captioning
- IP Captioning
- Remote GUI
- Event Scheduler
- AES Input
- Analog Audio Input
- SDI Embedded Audio Input
- HDMI Embedded Audio Input
- 2 thru 4 Line Roll-up Captions
- Selectable Caption Location
